Shelly Pro Dimmer Smart Switch WiFi, 0-10V, Output 230V 200W, Energy Meter
SKU: SH-PRODIMMER-0-10V
- 51.00 €
-
- Customer price 48.45 € -5%
- Log in and get at least a 5% discount
To submit Liisy payment by installment application add products to cart, choose Liisi payment by installment as the payment method and cofirm your order. After confirming the order Liisi application will appear. Calculations are approximate and may differ from conditions offered to you.
Pealadu
Tallinn, Peterburi tee 90F
Tallinn, Peterburi tee 90F
1 pcs
Peterburi tee Oomipood
Tallinn, Peterburi tee 90F
Tallinn, Peterburi tee 90F
2 pcs
Järve keskuse Oomipood
Tallinn, Pärnu mnt. 238
Tallinn, Pärnu mnt. 238
2 pcs
Lõunakeskuse Oomipood
Tartu, Lääneringtee 39
Tartu, Lääneringtee 39
2 pcs
Põhjakeskuse Oomipood
Rakvere, Haljala tee 4
Rakvere, Haljala tee 4
0 pcs
Kaubamajaka Oomipood
Pärnu, Papiniidu 8
Pärnu, Papiniidu 8
1 pcs
A smart dimmer that allows you to control and adjust lighting to suit your needs. With Wi-Fi and LAN connectivity, as well as energy consumption monitoring, it is the perfect solution for precise and energy-efficient home lighting control. The device supports various light sources, including dimmable LEDs and halogen lamps.
Features:
Supports dimmable LEDs, halogen lamps, and incandescent bulbs.
Real-time energy consumption monitoring.
Connectivity: LAN and Wi-Fi for a stable connection.
Compatibility with Google Assistant and Amazon Alexa.
Protection against overload and overheating.
Operating voltage: 110–230V AC, 50/60 Hz.
Built-in timers for automated control.
Compact design: Fits into standard electrical panels.
Applications:
Ideal for adjusting lighting in living spaces, offices, and commercial areas. Perfect for creating comfort and a stylish ambiance.
Features:
Supports dimmable LEDs, halogen lamps, and incandescent bulbs.
Real-time energy consumption monitoring.
Connectivity: LAN and Wi-Fi for a stable connection.
Compatibility with Google Assistant and Amazon Alexa.
Protection against overload and overheating.
Operating voltage: 110–230V AC, 50/60 Hz.
Built-in timers for automated control.
Compact design: Fits into standard electrical panels.
Applications:
Ideal for adjusting lighting in living spaces, offices, and commercial areas. Perfect for creating comfort and a stylish ambiance.
Size (HxWxD): 94x19x69 mm
Weight: 75 g
Screw terminals max torque: 0.4 Nm
Conductor cross section:
0.5 to 2.5 mm² / 20 to 14 AWG (green connectors)
0.5 to 1.5 mm² / 20 to 16 AWG (blue connector)
Conductor stripped length:
6 to 7 mm (green connectors)
5 to 6 mm (blue connector)
Mounting: DIN rail
Ambient working temperature: -20 °C to 40 °C
Humidity: 30 % to 70 % RH
Max. altitude: 2000 m
Power supply: 110 - 240 V~ 50/60 Hz
Power consumption: < 2 W
External protection:
10 A, tripping characteristic B or C
6 kA interrupting rating
Energy limiting class 3
Dimming type: Trailing edge
Max. output power: 200 W
Voltmeter (AC): Yes
Ammeter (AC): Yes
Power and energy meters: Yes
Internal-temperature sensor: Yes
Radio:
Wi-Fi:
Protocol: 802.11 b/g/n
RF band: 2401 - 2483 MHz
Max. RF power: < 20 dBm
Range: Up to 30 m indoors and 50 m outdoors (Depends on local conditions)
Bluetooth:
Protocol: 4.2
RF band: 2400 - 2483.5 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m indoors and 30 m outdoors (Depends on local conditions)
Weight: 75 g
Screw terminals max torque: 0.4 Nm
Conductor cross section:
0.5 to 2.5 mm² / 20 to 14 AWG (green connectors)
0.5 to 1.5 mm² / 20 to 16 AWG (blue connector)
Conductor stripped length:
6 to 7 mm (green connectors)
5 to 6 mm (blue connector)
Mounting: DIN rail
Ambient working temperature: -20 °C to 40 °C
Humidity: 30 % to 70 % RH
Max. altitude: 2000 m
Power supply: 110 - 240 V~ 50/60 Hz
Power consumption: < 2 W
External protection:
10 A, tripping characteristic B or C
6 kA interrupting rating
Energy limiting class 3
Dimming type: Trailing edge
Max. output power: 200 W
Voltmeter (AC): Yes
Ammeter (AC): Yes
Power and energy meters: Yes
Internal-temperature sensor: Yes
Radio:
Wi-Fi:
Protocol: 802.11 b/g/n
RF band: 2401 - 2483 MHz
Max. RF power: < 20 dBm
Range: Up to 30 m indoors and 50 m outdoors (Depends on local conditions)
Bluetooth:
Protocol: 4.2
RF band: 2400 - 2483.5 MHz
Max. RF power: < 4 dBm
Range: Up to 10 m indoors and 30 m outdoors (Depends on local conditions)
