1 channel 5v/dc self-locking relay module 250VAC 10A

The OKY3011-4 is a versatile 1-channel self-locking relay module, providing enhanced isolation and protection for remotely controlling electrical circuits. This module allows a low-voltage signal to efficiently manage a high-voltage or high-current circuit.

Overview

The OKY3011-4 relay module incorporates a bistable relay, ensuring it maintains its on or off state even after the control signal is removed. This self-locking functionality is easily activated using a single button or trigger signal to toggle the relay's state. It is ideally suited for use with microcontrollers such as Arduino, AVR, PIC, DSP, ARM, MSP430, and TTL logic.

Key Features

- Self-Locking Functionality: Toggles the relay state with each trigger pulse.

- Single-Chip Microcomputer Control: Delivers stable, reliable performance with strong anti-interference capabilities.

- Reverse Protection Diode: Safeguards against damage from reverse polarity connections.

- Double-Sided PCB Design: Enhances the module's durability and overall reliability.

- High Voltage Regulator Tube: Guarantees a stable voltage supply with effective heat dissipation.

- External Trigger Compatibility: Can be easily triggered by an external switch.

- LED Indicators: Provides clear visual indication of power and relay status.

- Optocoupler Isolation: Offers crucial electrical isolation between the control circuit and the load.

Versatile Use Cases and Benefits

- Home Automation: Effortlessly control lights, fans, and other appliances remotely.

- Industrial Control: Automate machinery and equipment for increased efficiency.

- Robotics: Precisely control motors, actuators, and other robotic components.

- Automotive Electronics: Manage car accessories and systems with ease.

- Remote Control Systems: Implement remote switching and control functions seamlessly.

Additional Information

The module benefits from a double-sided PCB design, ensuring enhanced durability. It also includes a tact switch for convenient direct product testing. The control pin incorporates a pull-down circuit to prevent malfunctions due to a vacant state. The relay is rated for an impressive 1 million switches.

Operating Instructions

1. Connect the appropriate DC power supply according to the voltage version of the module.

2. Be aware that the module may exhibit slight heating during operation, which is normal.

3. Ensure that the load power remains within the relay's specifications to avoid impacting the product's lifespan.
