Image is for illustrative purposes only
Laboratory Power Supply 0...120VDC 0...3A LED SMPS
- 189.00 €
-
- Customer price 179.55 € -5%
- Log in and get at least a 5% discount
Tallinn, Peterburi tee 90F
Tallinn, Peterburi tee 90F
Tallinn, Pärnu mnt. 238
Tartu, Lääneringtee 39
Rakvere, Haljala tee 4
Pärnu, Papiniidu 8
The Geti GLPS 1203H laboratory power source is intended for powering a variety of electronic devices. It smoothly regulates the output voltage and output current. It reliably maintains the set values regardless of fluctuations in the supply voltage or the connected load. The output voltage is adjustable between 0V - 120V and the output current is adjustable 0A - 3A. The stability and ripple factor of the source are very good. The device can be operated as a source of constant voltage or as a source of constant current. The device is equipped with short-circuit protection so that in case of an unexpected event it is safe for the user and at the same time it is not destroyed. The power supply is suitable for work in laboratories, workshops, electronics production lines, companies repairing household appliances, DIY, but also as a teaching aid in schools.
Product parameters:
- single-channel direct current source
- adjustable voltage and current
- backlit triple LED display for U(V), I(A) and P(W)
- high-quality and compact design
- overload protection
- USB 5V / 2A
Output voltage range: DC 0 - 120 V, coarse+fine regulation
Output current range: 0 - 3 A, coarse+fine regulation
Supply voltage: 220-230V AC, 50 Hz
Constant voltage condition:
- voltage stability ≤0.2% ± 3 mV
- low voltage 0.3 - 0.4% ± 3 mV
- load stability ≤0.5% ± 3 mV
- ripple and noise ≤150mVp-p
Constant Current Status:
- current stability ≤0.2% ± 3 mA
- load stability ≤0.2% ± 3 mA
- ripple and noise ≤20mAms
Display accuracy: 0.5% ± 2 digits
Display resolution: voltage 00.01 V / 0.01 V
Display resolution: current 0.001 A / 0.01 A
Working temperature 0 °C - 40 °C
Operating humidity <80% RH
Weight: 1.4 kg
Dimensions: 220 x 85 x 150 mm
Standard fuse: T5A
